Analysis Techniques & Strategies

Bollinger Bandwidth (Indicator)

image\trumpet2.gif Disclaimer


Input Information

Name Expression Default Description
BollingerPrice Numeric Close Price on which the calculation of the bands is based.
Length Numeric 20 Number of bars of data to be considered.
NumDevsUp Numeric 2 Number of standard deviations used to calculate the upper Bollinger Band.
NumDevsDn Numeric -2 Number of standard deviations used to calculate the lower Bollinger Band.
Displace Numeric 0 Number of bars to displace the plot of the Bollinger Bands.

Market Synopsis

The Bollinger Bandwidth indicator calculates and plots the difference between the upper and lower Bollinger Bands, divided by the value of the moving average that is usually plotted as the middle line between the upper and lower bands.

A higher plotted value indicates that the bands are further apart and a lower plotted value indicates that the bands are closer together.

Plot Information

Number Name Default Color Description
Plot1 Bandwidth Yellow Plots the Bollinger Bandwith.

When applied to a chart, this indicator displays plots in a separate subgraph.

Related Functions

AverageFC

StandardDev
